· Grades：304、304H、316、316L、201Cu 、200CU 、 430 、D66
· Performance: Good wear resistance, corrosion resistance, good elasticity, fine and bright surface, good formability and weld ability
Physical properties of stainless steel hardness wire:
1/4H stainless steel wire
Type
Dia. MM
T/S N/MM2
Sus304/sus304H/sus316/sus316L/sus201/430
0.05-1.60
830 -1180
Sus304/sus304H/sus316/sus316L/sus201/430
1.60-3.00
780 -1130
Sus304/sus304H/sus316/sus316L/sus201/430
3.00-6.00
730 -1080
1/2H stainless steel wire
Type
Dia. MM
T/S N/MM2
Sus304/sus304H/sus316L/sus201/430
0.05-1.60
1130 -1470
Sus304/sus304H/sus316L/sus201/430
1.60-3.00
1080 -1420
Sus304/sus304H/sus316L/sus201/430
3.00-6.00
1080 -1420
3/4H full hardness stainless steel wire
mm Dia.
（N/mm2）T/S
WPA3/4
WPB
0.08-0.20
1650-1900
2150-2400
0.23-0.40
1600-1850
1950-2300
0.45-1.00
1530-1780
1850-2100
1.20-2.00
1400-1700
1650-2000
2.30-4.00
1230-1570
1450-1800
No.
Spool Model
Outer Diameter
Trunk
Inner
Inner Height(L2)
Total height
Weight of Spool
Rated load weight
1
DIN 125
125mm
65mm
20-25mm
100mm
120mm
0.18kg
2-3kg
2
DIN 160
160mm
99.3mm
22.03mm
129mm
160mm
0.3kg
5-7kg
3
DIN 200
200mm
125.31mm
23.06mm
160mm
200mm
0.62-0.66kg
10-15kg
4
DIN 250
250mm
160mm
20.73mm
160mm
200mm
1kg
20-25kg
5
NS-4
118.83mm
75.4mm
21.27mm
129.33mm
148.14mm
2-3kg
(d1)
Diameter(d2)
Diameter(d3)
(L1)
CHEMICAL PROPERTIES
|
Chemical Properties of Frequently-used Stainless Steel Material Grade |
|||||||||||
|
UNS |
ASTM |
EN |
JIS |
C% |
Mn% |
P% |
S% |
Si% |
Cr% |
Ni% |
Mo% |
|
S20100 |
201 |
1.4372 |
SUS201 |
≤0.15 |
5.5-7.5 |
≤0.06 |
≤0.03 |
≤1.00 |
16.0-18.0 |
3.5-5.5 |
- |
|
S20200 |
202 |
1.4373 |
SUS202 |
≤0.15 |
7.5-10.0 |
≤0.06 |
≤0.03 |
≤1.00 |
17.0-19.0 |
4.0-6.0 |
- |
|
S30100 |
301 |
1.4319 |
SUS301 |
≤0.15 |
≤2.00 |
≤0.045 |
≤0.03 |
≤1.00 |
16.0-18.0 |
6.0-8.0 |
- |
|
S30400 |
304 |
1.4301 |
SUS304 |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.03 |
≤0.75 |
18.0-20.0 |
8.0-10.5 |
- |
|
S30403 |
304L |
1.4306 |
SUS304L |
≤0.03 |
≤2.00 |
≤0.045 |
≤0.03 |
≤0.75 |
18.0-20.0 |
8.0-12.0 |
- |
|
S30908 |
309S |
1.4833 |
SUS309S |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.03 |
≤0.75 |
22.0-24.0 |
12.0-15.0 |
- |
|
S31008 |
310S |
1.4845 |
SUS310S |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.03 |
≤1.50 |
24.0-26.0 |
19.0-22.0 |
- |
|
S31600 |
316 |
1.4401 |
SUS316 |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.03 |
≤0.75 |
16.0-18.0 |
10.0-14.0 |
2.0-3.0 |
|
S31603 |
316L |
1.4404 |
SUS316L |
≤0.03 |
≤2.00 |
≤0.045 |
≤0.03 |
≤0.75 |
16.0-18.0 |
10.0-14.0 |
2.0-3.0 |
|
S31703 |
317L |
1.4438 |
SUS317L |
≤0.03 |
≤2.00 |
≤0.045 |
≤0.03 |
≤0.75 |
18.0-20.0 |
11.0-15.0 |
3.0-4.0 |
|
S32100 |
321 |
1.4541 |
SUS321 |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.03 |
≤0.75 |
17.0-19.0 |
9.0-12.0 |
- |
|
S34700 |
347 |
1.4550 |
SUS347 |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.03 |
≤0.75 |
17.0-19.0 |
9.0-13.0 |
- |
|
S40500 |
405 |
1.4002 |
SUS405 |
≤0.08 |
≤1.00 |
≤0.04 |
≤0.03 |
≤1.00 |
11.5-14.5 |
≤0.60 |
- |
|
S40900 |
409 |
1.4512 |
SUS409 |
≤0.08 |
≤1.00 |
≤0.045 |
≤0.03 |
≤1.00 |
10.5-11.75 |
≤0.50 |
- |
|
S43000 |
430 |
1.4016 |
SUS430 |
≤0.12 |
≤1.00 |
≤0.040 |
≤0.03 |
≤0.75 |
16.0-18.0 |
≤0.60 |
- |
|
S43400 |
434 |
1.4113 |
SUS434 |
≤0.12 |
≤1.00 |
≤0.040 |
≤0.03 |
≤1.00 |
16.0-18.0 |
- |
- |
|
S44400 |
444 |
1.4521 |
SUS444L |
≤0.025 |
≤1.00 |
≤0.045 |
≤0.03 |
≤1.00 |
17.5-19.5 |
≤1.00 |
- |
|
S40300 |
403 |
- |
SUS403 |
≤0.15 |
5.5-7.5 |
≤0.04 |
≤0.03 |
≤0.50 |
11.5-13.0 |
≤0.60 |
- |
|
S410000 |
410 |
1.40006 |
SUS410 |
≤0.15 |
≤1.00 |
≤0.035 |
≤0.03 |
≤1.00 |
11.5-13.5 |
≤0.60 |
≤1.00 |
|
S42000 |
420 |
1.4021 |
SUS420J1 |
0.16~0.25 |
≤1.00 |
≤0.04 |
≤0.03 |
≤1.00 |
12.0-14.0 |
≤0.75 |
≤1.00 |
|
S440A |
440A |
1.4028 |
SUS440A |
0.60~0.75 |
≤1.00 |
≤0.04 |
≤0.03 |
≤1.00 |
16.0-18.0 |
- |
≤0.75 |
|
S32750 |
SAD2507 |
1.4410 |
≤0.03 |
≤1.2 |
≤0.035 |
≤0.02 |
≤0.80 |
24.0-26.0 |
6.0-8.0 |
3.0-5.0 |
|
|
S31803 |
SAF2205 |
1.4462 |
≤0.03 |
≤2.0 |
≤0.03 |
≤0.02 |
≤1.00 |
21.0-23.0 |
4.0-6.5 |
2.5-3.5 |
|
|
N08904 |
904L |
1.4539 |
≤0.0.3 |
≤2.0 |
≤0.035 |
≤0.03 |
≤1.00 |
18.0-20.0 |
23.0-25.0 |
3.0-4.0 |
|
